Key Specifications/Special Features:

10.1” 350 cd/m² TFT LCD with capacitive touch
Intel® Atom™ N2800 1.86GHz processor
Powered by Windows® Embedded Standard 7 P
Bluetooth, Wi-Fi, 3.75G wireless with GPS
1D/2D barcode reader, 13.56MHz RFID reader
1.3-megapixel CMOS front camera and 5-megapixel CMOS rear camera
Optional built-in hot- swappable battery

Specifications:



Display
LCD Size	10.1" TFT LCD
Brightness (cd/m2)	350
Max Resolution	1280 x 800
Touch Screen	Capacitive type
Viewing Angle	85/85/85/85 Deg
System
CPU	Intel® Atom™ N2800 1.86GHz
Chipset	Intel® NM10
Operating System	Windows® Embedded Standard 7 P
Memory	On-board 4GB DDR3
Storage	8GB mSATA
Communication
Wireless Lan	Wi-Fi 802.11/b/g/n
Bluetooth	Bluetooth 3.0
Modem	UMTS/HSUPA Band 1,2,4,5,6,8
GPS	GPS with internal antenna
Data Collection
RFID	13.56MHz RFID supports ISO14443A/B (Mifare, Felica)
Barcode	1D/2D Imager Scan Engine
Camera (Front)	1-3 Megapixels CMOS camera 5 Megapixels rear camera
Indicator & Buttons
Keys	1 x Power button 2 x Hot Keys 1 x Menu
LED Indicator	Battery charging/peripheral device/storage/wireless device
I/O Interface
Audio	1 x Headphone 1 x Mic-in 2 x 1 W speakers
Expansion	1 x USB combo 1 x USB 3.0 1 x SIM card slot 1 x Micro HDMI
Power
Power adapter	Input AC: 100~240V Output DC: 19V / 3A
Battery	40 W standard battery pack (5 working hours) 40 W optional battery pack (5 working hours)
Environment
Operating Temperature	0°C to +40°C
Storage Temperature	-20°C to -60°C
Humidity	5%~95% non-condensing
Drop Survival	1.2M
Environmental Protection	IP54
Certification	CE/FCC
Dimensions (LxWxH) (mm)	297x234x32
Weight	1.9kg
