Key Specifications/Special Features:

• CPU : 32 bits MCU ,40 MHz , 16KB SRAM, 128KB Flash ROM
• Support Modbus TCP
• LoRa Semtech SX1272
  • Freq. : ISM band 86 862 ~ 936MHz
  • Receiver Sensitivity : -137 dBm
  • Transmit Output Power : 20 dBm
  • Sleep Current : 3 3uA (at power down state)
  • TX current < 140 mA@20 dbm , RX current < 10 mA
  • Security processor ( 128/192/256 bits AES )
  • Packet engine up to 256 bytes with CRC
  • Antenna : SMA Type , 2 dBi , changeable
  • Distance : Up To 1500~7500 Meters in free space
  • Data Rate : 0.244 ~ 18.2K bps ( LoRa ) / 300 K bps (FSK)
  • Application mode : Star
• Ethernet Port
  • Port Type：RJ-45 Connector
  • Speed：10 / 100 Mbps ( Auto Detect )
  • Protocol：ARP , IP , ICMP , UDP , TCP , HTTP , DHCP
  • Mode：TCP Server / TCP Client / UDP
  • Setup：HTTP Browser Setup ( IE )
  • Security：Login Password
  • Protection：Built-in 1.5KV Magnetic Isolation
  • Modbus TCP To RTU /ASCII Slave Mode
  • Modbus RTU /ASCII To TCP Slave Mode
• Setup Tool : Windows Utility
• Power : DC 9 ~ 24V / 150mA@ 9V , 60mA@ 24V
• Power consumption: 12VDC / 95 mA, 9VDC / 120mA
• Led Lamp : SYS (green) , Rx(red) , Tx(green)
• Environment: Operating Temperature: 10〜70℃, Storage Temperature: 20〜80℃
• Dimensions : 100 * 90 * 25 mm ( W * D * H )
• Weight : 150 gm ( not include power )
